ISO Approved Electro Magnetic Iron Separator In Czech Republic

ISO Approved Electro Magnetic Iron Separator In Czech Republic

Model:RCDA-5 Electric Magnetic Iron Separator
RCDA series wind cooling electromagnetic iron separator is designed by our own company basing advanced technology.Large heat releasing area,low temperature rise,good cooling performance are the Distinct advantages.It is pretty suitable for Czech Republic.The internal excitation coils use air-conditioning fans or axial flow fan to cool the separator. When the iron separator is in a good working environment, air-conditioning fans sparse the heat; When the magnetic separator is in a harsh working environment (for example, plenty of dust, coal dust, smoke), axial flow fans sparse the heat. This product has a reasonable structure, low failure rate and a wide use range.we are professional on exporting mining machinery,welcome to visit our factory.

Print Product Summary

*Brand:Baite
*Color:Multi Color
*Voltage:380V
*Weight:1T
*Material:Stainless Steel
*Warranty Period:1 Year
*Country Of Origin:Shandong, China (Mainland)
*After-Sales-Service:Technical Service
*Dimension:Customized
*Price:Negotation

rechal@baitecidian.com

+86-536-8309116

Specification

product details.jpg

Large heat releasing area,low temperature rise,good cooling performance are the Distinct advantages of RCDA series suspended magnetic iron separator. RCDA suspended magnetic iron separator is an air cooled electromagnetic iron separator. The internal excitation coils use air-conditioning fans or axial flow fan to cool the separator. When the iron separator is in a good working environment, air-conditioning fans sparse the heat; When the magnetic separator is in a harsh working environment (for example, plenty of dust, coal dust, smoke), axial flow fans sparse the heat. This product has a reasonable structure, low failure rate and a wide usage range. This machine is usually suspended over the conveyor belt to collect ferrous elements from non-magnetic materials before the crushing or milling process, and so as to protect the crushing and milling machines.

0 electromagnetic ore separator exporter.jpg

Technical Features
-- Strong magnetic intensity and special design for magnetic circuit.
--  The sealed structure makes the separator water-proof, dust-proof and corrosion resisting.
--  Low energy consumption.
--  Easy to install and convenient to use.
--  High efficiency and stable performance.

4 electromagnetic separator manufacturers.jpg

6 electromagnetic separator.jpg

9 electromagnetic separator exporter.jpg

Overal Dimension Drawing

Working Principle Drawing

Technical Parameter

NO.	Model	conveyor belt width (mm)	Suspension height（h=mm）	Material depth（≤mm）	Magnetic intensity（≥mt）	Belt speed（m/s）	Existing power （≤kw）	Condenser power （≤kw）	Weight（kg)	Appearance size(mm)
NO.	Model	conveyor belt width (mm)	Suspension height（h=mm）	Material depth（≤mm）	Magnetic intensity（≥mt）	Belt speed（m/s）	Existing power （≤kw）	Condenser power （≤kw）	Weight（kg)	A	B	C	D
1	RCDA-4	400	100	70	50	4.5	0.6	0.15	350	610	400	240	240
2	RCDA-5	500	150	90	60		1.0	0.15	450	710	500	340	340
3	RCDA-6	600	175	120	60		1.6	0.37	620	910	600	500	500
4	RCDA-6.5	650	200	150	70		2.0	0.37	750	990	650	780	650
5	RCDA-8	800	250	200	70		4.0	0.37	980	1080	800	870	740
6	RCDA-10	1000	300	250	70		6.0	0.55	1330	1400	1000	1250	1040
7	RCDA-12	1200	350	300	70		8.0	0.55	1950	1600	1200	1400	1240
8	RCDA-14	1400	400	350	70		12.0	0.75	2870	1910	1400	1560	1400
9	RCDA-16	1600	450	400	70		15.0	0.75	3800	2010	1600	1760	1600
10	RCDA-18	1800	500	450	70		20.0	1.5	4500	2360	1800	2000	1800
Note:All themodels have T1、T2、T3design whose magnetic intensity is higher than standard.The magnetic 90mt,120mt and 150mt separately,Discard iron belt can be equipped with armor.

company information.jpg

There is no better , only better.
Weifang baite Magnet Technology Co., Ltd . is a modern joint-stock enterprise, which is producing magnetic and power equipment .The service is related to more than 10 areas ,such as electricity , coal ,building materials, metallurgy ,ports ,mining ,nonferrous metals ,power environmental production .At present ,we have provided more than 3000 domestic customers with reliable and value-added and convenient professional equipment and programes, and at the same time ,we occupy more than 60%magnetic separation equipmemt matching share of China ball mill, crusher, iron sand ship and other production industry, Baite has firmly implemented IS09001:2000 international quality magnagement system standard and IS010012 international quality inspection system standard.

new customer visiting.jpg
