• *Brand:Baite
• *Color:Multi Color
• *Voltage:380V
• *Weight:1T
• *Material:Stainless Steel
• *Warranty Period:1 Year
• *Country Of Origin:Shandong, China (Mainland)
• *After-Sales-Service:Technical Service
• *Dimension:Customized
• *Price:Negotation

Basic info:

Model:RCDD Dry Powder Magnetic Separator

Belt Width:500-1800mm

Suspension height:150-500mm

Magnetic intensity:60-150mT

Thickness of materials:100-450mm

Excitation power:1-18kw

Power:1.5-7.5kw

Belt speed:4.5m/s

Weight:950-7800kg

RCDD dry electromagnetic separator is a self-cleaning type equipment for removal of the powder and block of non-magnetic materials.

This series electromagnetic separator is suitable for removing ferromagnetic foreign from more thick material layer and larger grain ore, coal, coke, limestone, etc.

Adsorptive capacity: 0.1 to 35 kg of ferromagnetic material

High intensity:magnetic force does not exceed 3% within 10 years

The central magnetic field intensity of the rated suspension height of the electromagnetic separator reaches 90mT, 120mT and 150mT respectively. The corresponding magnetic field gradients are 1.57 times and 2 times of the national standard degaussing device magnetic gradient respectively. 6 times, 3.28 times. Through comparison, we can learn that the suction of this series of super magnetic and magnetic iron removers at the rated suspension height is 2.24 times, 4.49 times and 7.8 times of the national standard iron remover respectively.

Technical Feature

1.Sustain and reliable magnetic field,with strong magnetic force.

1.Compact structure,light weight and easy to maintain.

2.It is a kind of automatic type for removing iron equipment.

3.Featuring with dust and rain-protection,wearing erosion,it can run in the harsh environment.

4.Low energy consumption,reliable performance.

Dimension

Technical Parameters

Application

It is widely used in coal,thermal power,building materials,mining,abrasive tools,refractory materials,non-metallic minerals,carbon black,food,feed and chemical industries.

Work Principle

There is no better , only better.
Weifang baite Magnet Technology Co., Ltd . is a modern joint-stock enterprise, which is producing magnetic and power equipment .The service is related to more than 10 areas ,such as electricity , coal ,building materials, metallurgy ,ports ,mining ,nonferrous metals ,power environmental production .At present ,we  have provided more than 3000 domestic customers with reliable and value-added and convenient professional equipment and programes, and at the same time ,we occupy more than 60%magnetic separation equipmemt matching share of China ball mill, crusher, iron sand ship and other production industry, Baite has firmly implemented IS09001:2000 international quality magnagement system standard and IS010012 international quality inspection system standard.

Factory Advantages & Service
Baitemagnet factory for general users and special users design and production of various types of customized products.The company owns 3, 000 square meters of mine machinery production plant in linqu area of weifang, and each product has a separate workshop to assemble specialized production workers.Most of our products are self-developed products, combining with advanced technology at home and abroad to ensure that the industry is competitive and fully meets the technical requirements of customers.Our production capacity is strong, and we have a special production line for customers who are in urgent need of the goods.
We are full of enthusiasm, high quality service, think the customer value is the principle. Provide the spare parts and vulnerable parts of the products at the factory price.
Once the equipment failure in the process of production, the company within 24 hours to the customer's phone must come up with a clear solution, and to resume production first and then the responsibility attitude quickly solve the problem.
