Wholesale Large Lump Magnetic Separator Factory For Thailand
Wholesale Large Lump Magnetic Separator Factory For Thailand
Wholesale Large Lump Magnetic Separator Factory For Thailand
Dry Magnetic Drum Separator is a hot selling machine in Thailand.We are a professional factory for dry magnetic drum separator,its magnetic system of dry magnetic separator is made of high quality ferrite material or combined with rare earth magnetic steel. According to the needs of users, we can provide downstream, semi-upstream, counter-current and other types of different surface strength of magnetic separation.It can be used for magnetic separation of magnetite, pyrrhotite, roasted ore, ilmenite and other materials
Print Product Summary
  • *Brand:Baite
  • *Color:Multi Color
  • *Voltage:380V
  • *Weight:1T
  • *Material:Stainless Steel
  • *Warranty Period:1 Year
  • *Country Of Origin:Shandong, China (Mainland)
  • *After-Sales-Service:Technical Service
  • *Dimension:Customized
  • *Price:500000
rechal@baitecidian.com
+86-536-8309116
Specification

Introduction

Dry type magnetic separator is for dry magnetic mineral separation magnetic separation machine, relative to the wet type magnetic separator to use liquid as diluent by sorting mineral separation efficiency, the dry type magnetic separator is asked to be sorting mineral dry, can move freely between particles and free state into separate, otherwise it will influence the magnetic separation effect, even will cause the consequences of not separation.Internal rotary magnetic separator is suitable for a variety of mineral separation, including hematite, vanadium ilmenite, single magnetite, mixed ore of magnetite and hematite, and iron removal of non-magnetic minerals, manganese ore, and particularly which is suitable for separating sea beach placer on sand dredger.

001 internal rotation magnetic separator.jpg

Technical Feature

1.2000-12000Gs.Adopting internal rotation permanent magnetic circuit, low energy consumption.

2.It can be configured with magnetic matrices to suit for the enrichment of minerals with different ratio susceptibility and can reduce the lower limit of recycling for granularity Level.

3.Large sorting space, no-blocking ,Partide sorting is from 0 to 20mm.

4.Transmitted by peripheral gear,Compact structure.

5.It can separate strong magnetic minerals and the weak at the same time.

04 internal rotation magnetic separator.jpg

Technical Parameters

Model


Diameter of separating cylinder mm



Width of separating area

Cylinder

Speed

 rpm

Working

Angle

˚

Maximum feeding

size

mm

Feed density

%

Magnetic

Induction

 intensity



Dry

ore

T/h

Power

kw

Weight

T

BTNX3812

950

3000

5-20

0-22

20mm

20-60

0.2-1.3

50-40

18.5

13

BTNX4812

1200

3000

5-20

0-22

20mm

20-60

0.2-1.3

120-180

22

18

BTNX5614

1400

3500

5-20

0-22

20mm

20-60

0.2-1.3

140-220

22

22

BTNX6414

1600

3500

5-20

0-22

20mm

20-60

0.2-1.3

170-270

25

26

BTNX7214

1800

3500

5-20

0-22

20mm

20-60

0.2-1.3

220-320

30

30

BTNX8014

2000

3500

5-20

0-22

20mm

20-60

0.2-1.3

260-400

35

36

BTNX8814

2200

3500

5-20

0-22

20mm

20-60

0.2-1.3

300-450

37

42

Note: We accept customized product according to customer requirements.

03 internal rotation magnetic separator.jpg

FAQ

1.Q: Can you provide samples?
A: Yes. We can make customized samples to you for quality checking and design confirmation.
2.Q: How long is the warrenty of your equipments? Does your company supply the spare parts?
A: The warranty period of Gelin equipments is one year. And of course we will supply the spare parts for you for life-long time at lowest cost.
3. How to make the payment?
we accept the payment by T/T or Western Union or Cash, L/C .For T/T, the customer can choose 100% in advance or 30% in advance, and pay the 70% balance before shipment.
4.Q: What is the shipping port?
A: Usually we ship from Qingdao port. If you want to ship from another port we can coordinate with you.
5.Q: What is the lead time?
A: 30-45 days after payment and production drawing confirmation.
6.Q: What is your MOQ?
A: Normally 1 piece is acceptable. Please consult with our sales for details.
