America RCDD 12 Electromagnetic Suspension Iron Separator
America RCDD 12 Electromagnetic Suspension Iron Separator
America RCDD 12 Electromagnetic Suspension Iron Separator
Model: RCDD 12 Electromagnetic Suspension Iron Separator
Self-cleaning is the most advantage of RCDD series electromagnetic separator.This type machine is designed by our company basing advanced technology.It is widely used in coal,thermal power,building materials,mining,abrasive tools and so on.It is greatly used in America.Whole sealed structure and dust-proof and water-proof make it can be worked in harsh environment.
Print Product Summary
  • *Brand:Baite
  • *Color:Multi Color
  • *Voltage:380V
  • *Weight:1T
  • *Material:Stainless Steel
  • *Warranty Period:1 Year
  • *Country Of Origin:Shandong, China (Mainland)
  • *After-Sales-Service:Technical Service
  • *Dimension:Customized
  • *Price:Negotation
rechal@baitecidian.com
+86-536-8309116
Specification

Table-Product Details.jpg

Model:RCDD dry powder magnetic separator

Belt width:500-1800mm

Suspension height:150-500mm

Magnetic intensity:60-150mT

Thickness of materials:100-450mm

Excitation power:1-18kw

Power:1.5-7.5kw

Belt speed:4.5m/s

Weight:950-7800kg

Electromagnetic separator has been widely used in many industries in China, especially in thermal power plants.Most industries have higher and higher requirements for product clutter removal.In large pieces of iron before entering the coal crusher in coal-fired power plants, it takes magnetic separator to remove iron. It can prolong the service life of coal pulverizer and reduce the maintenance rate and bring the huge benefit of security and stability. So,It plays an important role on removing iron from large pieces coal.

1 dry power magnetic separator1.jpg

Technical Feature

1.Sustain and reliable magnetic field,with strong magnetic force.

1.Compact structure,light weight and easy to maintain.

2.It is a kind of automatic type for removing iron equipment.

3.Featuring with dust and rain-protection,wearing erosion,it can run in the harsh environment.

4.Low energy consumption,reliable performance.

Dimension


0 electromagnetic separator.jpg

Technical Parameters

NO.Modelconveyor belt width  (mm)Suspension height(h=mm)Material depth(≤mm)Magnetic intensity(≥mt)Existing power (≤kw)Belt speed(m/s)Working systemDriving Power(kw)Weigh(kg)Appearance size(mm)
ABCDE
1RCDD-5500150100601.04.5Continuous1.5950202010407758531000
2RCDD-6600180130601.81.51380214011008009101100
3RCDD-6.5650200150702.01.51490227511908209881250
4RCDD-8800250200703.62.217702540148086512871350
5RCDD-101000300250705.03.023802750163594014201400
6RCDD-121200350300706.84.0317030001800101015801700
7RCDD-141400400350709.05.5480035002050105018002000
8RCDD-1616004504007013.07.5630039002450118022002350
9RCDD-1818005004508018.07.5780044002850129026002800
Note:All themodels have T1、T2、T3design whose magnetic intensity is higher than standard.The magnetic 90mt,120mt and 150mt separately,Discard iron belt can be equipped with armor.


Application

It is widely used in coal,thermal power,building materials,mining,abrasive tools,refractory materials,non-metallic minerals,carbon black,food,feed and chemical industries.

1 electromagnetic separator.jpg

2 magnetic separator.JPG

Work Principle

work principle picture.gif


Table-Company Introduction.jpg

There is no better , only better.
Weifang baite Magnet Technology Co., Ltd . is a modern joint-stock enterprise, which is producing magnetic and power equipment .The service is related to more than 10 areas ,such as electricity , coal ,building materials, metallurgy ,ports ,mining ,nonferrous metals ,power environmental production .At present ,we  have provided more than 3000 domestic customers with reliable and value-added and convenient professional equipment and programes, and at the same time ,we occupy more than 60%magnetic separation equipmemt matching share of China ball mill, crusher, iron sand ship and other production industry, Baite has firmly implemented IS09001:2000 international quality magnagement system standard and IS010012 international quality inspection system standard.

own company informantion.jpg

Factory Advantages & Service

Baitemagnet factory for general users and special users design and production of various types of customized products.The company owns 3, 000 square meters of mine machinery production plant in linqu area of weifang, and each product has a separate workshop to assemble specialized production workers.Most of our products are self-developed products, combining with advanced technology at home and abroad to ensure that the industry is competitive and fully meets the technical requirements of customers.Our production capacity is strong, and we have a special production line for customers who are in urgent need of the goods.
We are full of enthusiasm, high quality service, think the customer value is the principle. Provide the spare parts and vulnerable parts of the products at the factory price.
Once the equipment failure in the process of production, the company within 24 hours to the customer's phone must come up with a clear solution, and to resume production first and then the responsibility attitude quickly solve the problem.
