• *Brand:Baite
• *Color:Multi Color
• *Voltage:22V
• *Weight:1T
• *Material:Stainless Steel
• *Warranty Period:1 Year
• *Country Of Origin:Shandong, China (Mainland)
• *After-Sales-Service:Technical Service
• *Dimension:Customized
• *Price:Negotation

Introduction

WG series vacuum filter is a new kind of product designed and produced independently by our company. WG dry line of vacuum belt filters using the fixed vacuum box and adhesive tape in sliding vacuum box, a motion between vacuum box and adhesive tape sealing structure, vacuum negative pressure as the driving force to realize solid-liquid separation equipment. On the structure, filtering section along the length of horizontal direction to decorate, can complete filter, filter cake washing, continuous automatic slag discharge, filter cloth regeneration process operations, and mother liquor with the filter cake washing liquid can be segmented collection. It has the advantages of high filtration efficiency, large production capacity, good washing efficiency, low water filter cake, flexible operation and simple maintenance.

Technical characteristics

1. Modular design of overall structure, flexible assembly, easy to transport and installation.

2. High degree of automation; The material, filtration, washing, suction, discharge and cloth cleaning are all continuous automation, improve production efficiency, reduce operating costs, greatly reduce the labor intensity of workers and improve the working environment.

3. Quick filtration rate; The material passes through the precipitation area, the large particle is at the bottom, the small particles in the upper layer, the filter cake structure is reasonable, filtrate is permeable resistance small, can undertake thin layer quick filtration.

4. Convenient filtration process; Filter cake thickness and water wash. Reverse flow washing series, vacuum degree, filter speed arbitrary adjustment, to achieve the best filtering effect.

5. Good washing effect; Can realize multi-level horizontal or countercurrent washing, washing evenly and thoroughly, the mother liquid and cleaning liquid can be collected and reused separately according to the process.

6. The control system USES DCS technology, which can realize the on-site and remote automatic control.

The working principle

WG dry line of vacuum belt filters using the fixed vacuum box and adhesive tape in sliding vacuum box, a motion between vacuum box and adhesive tape sealing structure, vacuum negative pressure as the driving force to realize solid-liquid separation equipment. On the structure, filtering section along the length of horizontal direction to decorate, can complete filter, filter cake washing, continuous automatic slag discharge, filter cloth regeneration process operations, and mother liquor with the filter cake washing liquid can be segmented collection.
