Application:
It is the primary choice for crushing coal.
Roll crusher is also named double-roll crusher, roll-type crusher. It is widely used to crush the raw materials such as coal , coal gangue, coke , limestone, sulfur ore, phosphate rock and etc, which are usually crushed in middle or fine size by the way of roll extrusion .Roll crusher is widely used in the fields of ore dressing , chemical, cement , refractory, grinding materials , building materials , etc. And it has more excellent performance than the general machinery in crushing of building materials, particularly in crushing materials .
Features
1. Simple and compact structure,low noise, high efficiency .
2. The installation is flexible, basically needs no foundation.
3. The rollers' surface adopts anti-abrasive welding rod or exchangeable dental plate, the maintenance is simple.
4. Self-preservation ability is strong, the high-hardness materials (such as all sorts of metal block) won't break the equipment's parts when they enter the shredding breach.
5. The discharge gram size is adjustable, the minimum can reach 2-10 mm.
Principle of operation
This equipment adopts two motors, which take two rollers to rotate reversely by the decelerator. when the materials drop on the rollers through the charge hole,Under the friction of the rollers, they are dragged between the two rollers, grinded by the roller's crushing, the grinded materials are pushed rotatorily by the rollers.
Application
1. Widely applied to fine processing of building materials, metallurgy, chemical industry, coal etc crafts.
2. Especially applied to the finement of the clinker, adjusting the grinding mill grading can increase productivity 30-50%.
Technical Parameters
NO. | Model | Feeding size (mm) | Discharging size (mm) | Capacity (t/h) | Driving Power(kw) | Protcetion mode | Driving | |
Standard | Heavy type | |||||||
1 | 2PG0202PT | <10 | 0.5-5 | 0.5-10 | 2.2x2 | 3x2 | Spring or hydraulic triangular belt or coupling | Triangular belt or coupling |
2 | 2PG0404PT | <30 | 0.5-10 | 3-30 | 4x2 | 5.5x2 | ||
3 | 2PG0605PT | <40 | 0.5-20 | 6-50 | 11x2 | 15x2 | ||
4 | 2PG0806PT | <60 | 0.5-20 | 10-100 | 15x2 | 18.5x2 | ||
5 | 2PG1008PT(Y) | <80 | 0.5-30 | 15-130 | 22x2 | 30x2 | ||
6 | 2PG1208PT(Y) | <90 | 0.5-40 | 30-250 | 30x2 | 37x2 | ||
7 | 2PG1212PT(Y) | <90 | 0.5-40 | 40-350 | 45x2 | 55x2 | ||
8 | 2PG1612PT(Y) | <110 | 0.5-50 | 60-420 | 55x2 | 75x2 | ||
9 | 2PG1616PT(Y) | <110 | 0.5-50 | 75-550 | 90x2 | 110x2 | ||
10 | 2PG1816PT(Y) | <130 | 0.5-50 | 90-700 | 110x2 | 132x2 |
Note:The dimension can be customized according to the different requsts of users.
Factory Advantages & Service
Baitemagnet factory for general users and special users design and production of various types of customized products.The company owns 3, 000 square meters of mine machinery production plant in linqu area of weifang, and each product has a separate workshop to assemble specialized production workers.Most of our products are self-developed products, combining with advanced technology at home and abroad to ensure that the industry is competitive and fully meets the technical requirements of customers.Our production capacity is strong, and we have a special production line for customers who are in urgent need of the goods.
We are full of enthusiasm, high quality service, think the customer value is the principle. Provide the spare parts and vulnerable parts of the products at the factory price.
Once the equipment failure in the process of production, the company within 24 hours to the customer's phone must come up with a clear solution, and to resume production first and then the responsibility attitude quickly solve the problem.
