Electromagnetic Iron Separator Exporter In Belgium
Electromagnetic Iron Separator Exporter In Belgium
Electromagnetic Iron Separator Exporter In Belgium
Model:RCDF-6 Electromagnetic Iron Separator In Belgium
We are professional manufacturer and supplier for mining equipment from China.Our company has professional technical personnel and magnetic experts of Chinese top-ranked levels. All the products strictly enforce the CE And ISO standard and all the production process check by professional engineers,So all of our products quality is perfect. This series dry electric-magnetic separator is the key to separate iron ore in Belgium.Especially to eliminate the waste iron and protect extraction roll,crusher,mill and so on,suitable for various hash environment.According to different type belt width,it has a large number of types.All the models have T1,T2,T3 design whose magnetic intensity is higher than standard.
Print Product Summary
  • *Brand:Baite
  • *Color:Multi Color
  • *Voltage:220V
  • *Weight:1T
  • *Material:Stainless Steel
  • *Warranty Period:1 Year
  • *Country Of Origin:Shandong, China (Mainland)
  • *After-Sales-Service:Technical Service
  • *Dimension:Customized
  • *Price:Negotation
rechal@baitecidian.com
+86-536-8309116
Specification

product details.jpg

Series RCDF dry self-cleaning electromagnetic iron separator is a kind of magnetic equipment which is using in the iron removal from the nonmagnetic material . It usually be installed in the front or center of the belt conveyor. The strong magnetic will absorb the pieces of iron which mixed with the materials and dished out by the iron discharging belt, achieving the purpose of self-cleaning,and it can prevent the discharging belt longitudinal crack,and ensure that the breaker and grinder work normally .This series iron separator is widely used in electricity,mine,metallurgy,building material,coal dressing, chemical industry,etc.

0 electromagnetic separator exporter.jpg


Technical Feature

--  With the computer-simulating design of magnetic circuits, it has deep magnetic depth and high magnetic field intensity.

--  With special design of exciting coils, it has longitudinal and latitude cooling oil paths. The heat can be easily transformed to the cooling oil to lower the coil temperature.

--  The special designed wholly sealed coils are moisture-proof, dust proof and  corrosion prevention.

--  The corrugated heat-releasing wings enlarge the cooling area and effectively control the temperature rise.

--  Easy maintenance, self clean iron wastes, robust performance.

--  The waist-drum shape roller can rectify the belt automatically. With the wholly sealed bearing blocks, it can achive trouble-free operation for a very long time.

-- With near and remote control system, it has a wide application.

1 ore separator supplier.jpg

Make A Delivery

7 electromagnetic separator exporter.jpg

6 magnetic separator China exporter.jpg

5 magnetic separator supplier.jpg


Technical Parameters

NO.

Model

Adaptive belt width  (mm)

Suspension height（h=mm）

Material depth（≤mm）

Magnetic intensity（≥mt）

Belt speed（m/s）

Existing power （≤kw）

Driving Power（kw）

Weight（kg)

Appearance size(mm)

A

B

C

D

E

1

RCDF-4

400

100

60

50

4.5

0.6

1.5

300

600

400

620

360

360

2

RCDF-5

500

150

100

60

1

1.5

500

740

500

730

460

460

3

RCDF-6

600

175

125

60

1.5

1.5

650

840

600

760

560

560

4

RCDF-6.5

650

200

150

70

2

2.2

750

890

650

830

610

610

5

RCDF-8

800

250

200

70

3

2.2

1150

1024

800

850

760

760

6

RCDF-10

1000

300

250

70

4.5

3

1400

1300

1000

950

940

940

7

RCDF-12

1200

350

300

70

6

4

2780

1500

1200

1050

1160

1160

8

RCDF-14

1400

400

350

70

8.5

4

4200

1700

1400

1100

1360

1360

9

RCDF-16

1600

450

400

70

12.5

5.5

5700

2000

1600

1200

1540

1540

10

RCDF-18

1800

500

450

70

18

7.5

7300

2200

1800

1300

1740

1740

Note:All themodels have T1、T2、T3design whose magnetic intensity is higher than standard.The magnetic 90mt,120mt and 150mt separately,Discard iron belt can be equipped with armor.

company information.jpg

Company & Customer Visiting
There is no better , only better.
Weifang baite Magnet Technology Co., Ltd . is a modern joint-stock enterprise, which is producing magnetic and power equipment .The service is related to more than 10 areas ,such as electricity , coal ,building materials, metallurgy ,ports ,mining ,nonferrous metals ,power environmental production .At present ,we  have provided more than 3000 domestic customers with reliable and value-added and convenient professional equipment and programes, and at the same time ,we occupy more than 60%magnetic separation equipmemt matching share of China ball mill, crusher, iron sand ship and other production industry, Baite has firmly implemented IS09001:2000 international quality magnagement system standard and IS010012 international quality inspection system standard.
