Gz Series Modern Technology Electromagnetic Vibrating Feeder For Hot Sale

Vibrating feeder, the massive, granular materials from the storage bin evenly, timing, and continuously give into the device, can be broken in the sand and gravel production line continuous evenly feed machinery, and carries on the coarse screening for material, vibrating feeder in the production process, for the massive, granular and powdered materials from storage in the warehouse or funnel to the homogeneous continuous or quantitative feeding equipment. Can be stepless adjustment of quantificationally, and achieve the production process of centralized control and automatic control. To the belt conveyor, bucket elevator, feeding, screening equipment, etc. To the crusher, grinding mill, such as feeding, as well as for automatic batching, quantitative packaging, etc., and can be used in the process of automatic control, realize the automation of production process.

Print Product Summary

*Brand:Baite
*Color:Multi Color
*Voltage:22V
*Weight:1T
*Material:Stainless Steel
*Warranty Period:1 Year
*Country Of Origin:Shandong, China (Mainland)
*After-Sales-Service:Technical Service
*Dimension:Customized
*Price:Negotation

rechal@baitecidian.com

+86-536-8309116

Specification

Introduction:

The feeder with equal feeding,stable operation,safe and reliable,convenient operation and save energy is a more desirable equipment for rationing feeding,suitable for requirement of continual production. Generally applicable in industrial and mining enterprises of metallurgy,chemical,coal,electric power,mechanism,building and light industry,food and medicine. Feeding device for cement mill, belt conveyor,bucket elevator,crusher and grinder.
Working principle

Vibrating feeder consists of vibrating frame, spring, vibrator, motor vibrating device and motor. The vibrator is made of two fixed eccentric shafts whose gears are

jogged. When installation, the two gears must be jogged according to the sign. Through drive of the motor, the two eccentric shafts start rotating to produce a linea

r huge power which forces the feeder to vibrate. Through the vibration,the materials will slip and sling on the funnel, moving forward, when the materials pass the

screening part, smaller parts will fall down, and avoiding the further crushing, so screening purpose can be reached.

Features:

1. Exclusive vibrating technology.

2. Small in size and light in weight.

3. Simple structure, easy to install and use, low maintenance cost.

4. High efficiency and feeding capacity.

5. Good operational reliability and easy adjustment.

Technical Parameter

Type	Model	Capacity (t/h)		Feed partrcle size (≤mm)	Double amplitude (mm)	Power supply voltage (V)	Current(A)		Power（kw）	Supporting control and model	Weight(kg)
Type	Model	0°	-10°	Feed partrcle size (≤mm)	Double amplitude (mm)	Power supply voltage (V)	Working current	Said the current	Power（kw）	Supporting control and model	Weight(kg)
Basic model	GZ0	5	7	50	1.75	220	1.34	1	0.06	XK35	75
	GZ1	10	14	50			3.0	2.3	0.15		146
	GZ2	25	35	75			4.58	3.8	0.25		217
	GZ3	35	50	85			6.8	5.5	0.35		300
	GZ4	50	70	100			8.4	7	0.45		412
	GZ5	80	120	150			12.7	10.6	0.65		656
	GZ6	120	180	150			15	12	1.1		950
	GZ7	150	210	180			16.4	13.3	1.5		1212
	GZ8	250	350	200			24.6	20	3.0		1685
Sealed	GZ0F	4	5.6	40			1.34	1	0.06		77
	GZ1F	8	11.2	40			3	2.3	0.15		154
	GZ2F	20	28	40			4.58	3.8	0.25		246
	GZ3F	30	40	50			6.8	5.5	0.35		320
	GZ4F	40	56	60			8.4	7	0.45		360
	GZ5F	60	92	80			12.7	10.6	0.65		668
	GZ6F	95	120	80			15	12	1.1		1103
	GZ7F	120	168	80			16.4	13.3	1.5		1278
	GZ8F	150	200	100			18.2	15.5	3		1780
